ZHM 01/2 HP - Gear Flow Meters for High Pressure Applications with Autoclave connections - 0.02 up to 3.0 l/min.

Thanks to their robust design, gear flow meters are particularly suitable for volume flow measurements in high-pressure applications and in harsh conditions, for example, in offshore and submarine applications. The ZHM HP is suitable for applications where hydraulic fluids, additives and injections need to be measured or metered under high pressure.

Description
Downloads

Thanks to their robust design, gear flow meters are particularly suitable for volume flow measurements in high-pressure applications and in harsh conditions, for example, in offshore and submarine applications. The ZHM HP is suitable for applications where hydraulic fluids, additives and injections need to be measured or metered under high pressure.

Download datasheet

Download manual

Measuring Ranges 0.02 up to 3.0 l/min

Measuring Accuracy up to ±0.1 %

Repeatability ±0.05 % (under the same conditions)

Linearity ±0.5 % of actual flow (viscosity ≥ 30 mm²/s)

Materials

Housing: as per DIN 1.4404 [AISI 316L]
Gears: shaft per DIN 1.4122, 1.4501 [AISI F55].
Bearing: Stainless steel ball bearing, Tungsten carbide sleeve bearing
Seals: FKM, FFKM

Pressure up to 1,035 bar [15,000 psi]

Medium Temperature -40 °C up to +180 °C [-40 °F up to +356 °F] (others on request)
