Trafag EPI Pressure transmitter thin-film on steel 8287.84.3317.35

Art.nr.: 8287.84.3317.35.19.44.61
HS code : 9026.2000
Country of origin : CH
Range: 0...400 Bar / 1,000 Bar overpressure
Accuracy: 0.3% F.S.
Pressure Conn: G 1/4″male
Elec. Conn: M12x1, 5-pole
Output: 4...20mA
Damper ø 0.4 mm
Seal FPM
Mat No. : 53991

Range: 0 ... 400 bar
Output: 4 - 20 mA
Electrical connection: M12x1 5-pin
Process connection: G1/4″ male
Excellent long-term stability
High resistance to overpressure 1000 Bar
Fully welded steel sensor system without additional seals
Compact design
Accuracy: 0.3% FS

Pressure range (Bar)	0 … 10, 0 … 100, 0 … 16, 0 … 25, 0 … 250, 0 … 4, 0 … 40, 0 … 400, 0 … 6, 0 … 60, 0 … 600
Output	0 ... 10 VDC, 4 ... 20 mA
Overpressure max.	1000, 12, 120, 1500, 18, 30, 300, 48, 75, 750, 180
Nutrition	15 ... 32, 9 ...32
Brand	Trafag
