H-Tronic Water level switch with 10 mtr, WPS 3000 compact

Want to automatically refill your garden pond with fresh water? Do you want it
Set water levels in your cistern to a certain level? Or do you want leaking
Detect conductive liquids reliably? Here's the solution! The water level switch
WPS3000 compact monitors the level of conductive fluids and combines several functions in one compact device.
in one compact device. Thanks to the included water sensors, the water level switch recognizes
changes in the level of conductive liquids, such as water, in a liquid container. The
level switch controls 230 V AC devices connected via a relay, for example, a pump or solenoid valve.

Technical data
- Operating voltage: 230 V AC
- Power consumption: 2 W
- Max. switching power (ohmic load): 2300 W
- Ambient temperature: 0 ... +50 °C
- WPS3000 compact dimensions: 100 x 60 x 41 mm
- Water sensor dimensions: 98 x Ø 20 mm
- Weight WPS3000 compact/water sensor: 221/211 g
- Total weight: 643 g
- Protection class: IP20
- Cable length water sensor: 10 m each

Delivery Scope:
- Water level switch
- 2 water sensors with connection cables and wall mounting

The water level switch provides the following
benefits:
- Automated water level monitoring and control
- Any selectable switching point thanks to adjustable position of the water sensors
- Suitable for liquid containers made of concrete, plastic or metal
- No mains power on the water sensors
