Compact Flow switch Type: VH325M01111I51 | G1″ (DN25) connection (brass)

Technical Specifications:

• Switching function:
  - Contact closes with increasing current
  - Contact opens on decreasing current
  - Return possible
• Pressure rating PN 25
• Medium temperature -25 ... 110 ° C
• Ambient temperature -25 ... 80 ° C
• Electrical connection 1.5 meters of PVC cable
• Current switching max. 1 A
• Voltage switching max. 230 VAC, 48 VDC
• Rating max. 26 VA, 20 W
• Degree of protection EN 60529 IP65
