F2 ultrasonic flowmeter achieves seamless integration through non-contact measurement. F2 combines technologically advanced measurement technology with easy installation, impressive versatility and minimal maintenance. The flow meter is suitable for all sizes from DN20 to DN80 and is unaffected by the liquid medium, piping material and installation location.
Specifications
| Performance Index | |
| Flow Range | (0.03～5.0) m/s |
| Accuracy | Valued ±2% |
| Repeatability | 0.40% |
| Pipe Diameter Range (Optional) | DN20～DN80 |
| Measuring Medium | Water |
| Pipe Material (Optional) | Carbon steel, stainless steel, copper, PVC |
| Function Index | |
| Communication Interface | RS485 communication interface, support Fuji protocol and Modbus protocol |
| WIFI | Frequency range：2.412~2.484GHz |
| Transmitting power: 802.11b 16±2 dBm | |
| 802.11n 13±2 dBm | |
| 802.11g14±2 dBm | |
| Working temperature：-20~85℃ | |
| Theoretically, it can reach 40m transmission distance in an open environment | |
| Power Supply | 10～36VDC/500mA |
| Keyboard | 3touch keys |
| Display | 128×128 OLED |
| Temperature | Transmitter installation ambient temperature：-10℃～50℃ |
| Sensor measurement medium temperature： 0℃～60℃ | |
| Humidity | RH: 0～99%，no condensation |
| IP | IP54 |
| Working Pressure | 1.6MPa |
| Physical Characteristics | |
| Transmitter | All-in-one |
| Sensor | Clamp-on |
| Cable | φ5, 6 core electric cable, standard length：2m |
